Product features:
1. Outdoor highlight of 6000-7000 CD, high-definition, saving electricity.
2. There are many Chinese font and font to choose from, you can also enter the English, French, German, Greek, Russian and Japanese and other foreign language.
3. Can through the 3 g / 4 g/cluster control wireless control, through the server control multiple ads machine and monitor multiple ads machine, can send a machine for multiple ads broadcast content.
4. The super area and texting user display advertising information, advertising content users change, environmental protection, low consumption, security, system stability, statement supervision and control system.
5. Broadcast system with multimedia software, and broadcast a variety of flexible input information; Can play text messages, broadcast form can roll, roll, introduce derivation model, can move up, left, messages can be aired. Font, size, can be arbitrary choice, can be set playback speed, and multiple messages can be broadcast simultaneously broadcast, or with animation and image at the same time.
6. Maintain, installation is convenient and concise, the video is clear, no flicker.
7. High-end toughened glass security (optional).8. (light sensor probe), automatically adjust the brightness (optional).
9. Intelligent wet feeling, warm feeling (optional).
10. Camera monitoring (optional).
11. Speakers, remote voice interaction (optional).
12. GPS (optional).
Technical parameters:
Part Number | P3.84 |
Pixel Pitch | 3.84mm |
LED Configuration | SMD1919 |
Pixel Density | 52*52 |
Scanning Size | 13S |
Module size | 200*200mm |
Resolution | 208x364dot Double sided |
Body size | 920mm *1670mm*156mm |
Display size | 800mm *1400mm Double sided |
Brightness Intensity | ≥6000-7000CD/m2 |
Viewing Angle (H/V) | ＞120°/120° |
View Distance | ＞4m |
Gray Scale | 16Bit |
Display Scale | 16.7M |
Power | 220V |
Max.Power Consumption | 2000W/tai |
Ave.Power Consumption | 700W/tai |
Refresh Frequency | ≥2000HZ |
Weight | 85KG |
Operating Temperature | - 40℃~+50℃ |
Operating Humidity | 10~90% |
Installation | The side |
Environmental | OUTDOOR IP65 |
Control | 3G/4G，WIFI，Ethernet cable |
The power supply | Energy saving power |
Heat dissipation | Temperature control fan |
Environmental reporting | Synchronous fact weather conditions |
Light sensor probe (plus option) | Automatically adjust the brightness |
Intelligent wet feeling, warm feeling, can add other options) | Automatic detection and feedback |
Camera monitoring (plus options) | Remote monitoring |
Speakers (plus options) | Speakers, remote voice dialogue |
GPS (plus option) | The global positioning |
